Price: (£10,650.00 ex VAT) £12,780.00 (inc VAT)
12780.00 2024-05-19he DHYD90KSE is a large 3-phase diesel generator offering exceptional value for money. With a maximum output of 88kVA, its 1500rpm water-cooled diesel engine this machine is ideal for sole source of power applications as well as emergency backup standby use. The AVR type alternator is will provide you with a smooth output voltage whatever your application. Running at a low speed of 1500rpm as well as being water cooled this machine is designed and manufactured to provide you with years of reliable service.
The introduction of the Deutz engine coupled with the build quality of the Hyundai 1500rpm diesel gensets furthers the generator's overall specification and is the second batch of generators in the 1500rpm series that sees Hyundai use Deutz engines in collaboration. In 2012, Hyundai in the UK introduced their first Deutz powered machine and the success of that unit has seen the higher end range of their generators grow.
The generator is controlled by an MRS 10 InteliLite control panel. Its use friend interface provides a simple straightforward means of controlling the generator. The graphic display panel provides the operator with a wealth of information relating to generator output and status and engine temperature and run time.
The external canopy is built to provide a high level of protection against the elements and all weather conditions as well as reducing the ambient noise to a very low level.
All standard Hyundai 1500rpm diesel generators above 15kW are designed to be used as stationary generators for standby or prime power supply.
| Automatic Transfer Switch Packages | Package Includes | Cable Length |
| 1500ATS4P-4 | Three phase, 4 pole 125amp, ATS panel, ATS plug, comms cable, batt charger | 10 metres |
| 1500ATS4P-5 | Three phase, 4 pole 125amp, ATS panel, ATS plug, comms cable, batt charger | 15 metres |
| 1500ATS4P-6 | Three phase, 4 pole 125amp, ATS panel, ATS plug, comms cable, batt charger | 20 metres |
| ATS125-3 | Three phase, 4 pole 125amp ATS panel only |
| Manufacturer | Hyundai |
| Engine Manufacturer | Deutz |
| Engine Model | Deutz BF4M2012C |
| Fueled/Driven by | Diesel |
| Cooling Method | Water-cooled |
| Max. Engine Speed (rpm) | 1500 |
| Engine Capacity (cc) | 4800 |
| Engine Oil | 15w40 |
| Oil Capacity (l) | 8.5 |
| Starting Method | Electric |
| Phase | Three Phase |
| Frequency (Hz) | 50 |
| Max. Power Output (kVA) | 88 |
| Max. Power (kW) | 70 |
| Continuous Power (kVA) | 79 |
| Continuous Power (kW) | 63 |
| Frequency (Hz) | 50 |
| Alternator Type | 224G |
| Voltage Regulator | AVR |
| Voltage (V) | 230 / 400 |
| Current (A) | 114.0 |
| Max. Operating Temperature (°C): | 40 |
| ATS Port | Included |
| Fuel Tank Capacity (l) | 180 |
| Fuel Consumption (l/hr 50% load) | 19.3 |
| Maximum Run Time (hr) | 9.3 |
| Noise (dBA @ 1m) | 92 |
| Noise (dB @ 7m) | 65 |
| Warranty | 1 year parts, labour and carriage |
| Features | Block On Start Up, Emergency Stop, High Temperature On Water, Low Battery, Low Oil Level, Low Oil Pressure, Low Running On Engine |
| Portability: | Stationary |
| Weight (kg) | 1430 |
| Dimensions (L x W x H) | L: 2720 x W: 1050 x H: 1510 (mm) |
