Price: (£270.49 ex VAT) £324.59 (inc VAT)
324.59 2026-03-21Rating: 4.8/5 based on 6 review(s).
The HYCP5030 is powered by an 78.5cc 4-stroke recoil start petrol engine, with a large 1.6L fuel tank for long running. It's ideal for compacting loose soil, gravel and sand together to create a solid and even foundation, providing a cost-effective alternative to hiring for the building, construction and landscaping industries.
It's fitted with a large plate measuring 495mm x 320mm (L x W) for making quick work of large areas and has a travelling speed of 25m/min, with a compaction depth of 150mm. The V-belt is covered by a guard which protects it from the knocks and bumps of construction work.
The throttle control is conveniently mounted on the handle, which also has a soft grip cover for increased comfort. It's designed for building patios, driveways, block paving, garage extensions and conservatory foundations and the compactor plate comes with a paving pad to protect patios and block paving from any marks or damage during use.
To make storage easy, the handles can be folded down over the main unit.
The wheel kit is also available to assist with transporting the compactor from one job to the next.
All Hyundai compactor plates are covered by a Hyundai 3 year platinum warranty.
| Model | HYCP5030 |
|---|---|
| Start Method | Recoil |
| Compaction Depth (mm) | 150 |
| Plate Size (mm) | 495 x 320 |
| Centrifugal Force (N) | 8200 |
| Travel Speed (m/min) | 25 |
| Vibration value m/s² | 13.76 |
| Exciter Oil Capacity (ml) | 80 |
| Exciter Speed (RPM) | 5900 |
| Handle Type | Soft Grip |
| Safety Features | Oil Alarm |
| Engine Model | 152F |
| Engine Type | Hyundai 4-Stroke |
| Engine Size (cc) | 78.5 |
| Rated Power (hp) | 1.6 |
| Rated Speed (RPM) | 3600 |
| Fuel | Unleaded Petrol |
| Fuel Capacity (L) | 1.6 |
| Engine Oil | SAE30 or SAE15W40 |
| Engine Oil Capacity (ml) | 400 |
| Sound Level (db) | 91 |
| Gross Weight (kg) | 50 |
| Net Weight (kg) | 48 |
| Fully Assembled Dimensions (H x W x L) (mm) | 300 x 865 x 1040 |
| Package Dimensions (H x W x L) (mm) | 450 x 400 x 650 |
| Fuel/Power Source | Petrol |
| Product Type | Compactor Plate |
| Warranty (years) | 3 |
| Commercial Warranty (years) | 1 |
| Model EAN | 747150287850 |
| In The Box | HYCP5030 & Manual |
Brand: Hyundai
Identifier: HYCP5030
5/5
For the price, this is a really good compactor, it was ok to set up once I knew what i was doing and once in use, it just keeps going.
4/5
I used sitebox for the first time last week and ordered a wacker plate from them. I ordered it on the afternoon and it arrived the following day Excellent service. I have not used the product as yet but on first impressions it looks great.
5/5
great little machine for doing a sub base for patios. Most of jobs are threw the house so it's a perfect size. Just doing a front drive aprox 60 sq meters and standing up to the job. Do put oil in as its arrives empty.
5/5
Very competitely priced for the machine. Its actually very heavy duty, which was a nice surprise and also worked out cheaper than hiring one for a month (the duration of the job). Overall please with purchase.
5/5
Excellent service and machine just what we needed.
5/5
Very good service and machine does what it says on the box. Very satisfied.Jim Steele
