(Item No Longer Available - No Direct Replacement)
Quote Ref: @94041
Product ID: 120VS12_120VS24
Manufacturer: Warrior Winches
Price: (£399.17 ex VAT) £479.00 (inc VAT)
479.00 2025-06-27Our premium “Next Generation” Samurai range are even faster, with a lower current draw and now boast a revolutionary external brake, more capable of load holding & lowering, as well as ensuring there’s no heat build up in the drum.
Ideal for recovery and 4x4 applications. Outstanding features include high quality series wound double sealed motor with solid brass contacts, heavy duty 4 pin waterproof contactors, double sealed drum on maintenance free bearings and quiet, efficient full steel planetary gearing. Comes with stainless steel roller fairlead and fittings as standard. The 12V version comes complete with heavy duty integrated wireless remote.
| Rated Line Pull | 12000 lbs (5443 kg) |
|---|---|
| Motor | 12v : 6.7hp / 5.0kw24v : 8.0hp / 6.0kw |
| Gearing | 253:1 |
| Braking Action | External Brake |
| Drum Size - Dia x L | 63 x 223mm(2.48 x 8.78 in) |
| Cable - Dia x L | 10.2mm x 26m(0.4 in x 85 ft) |
| Dimensions | 559 x 160 x 248mm(22 x 6.3 x 9.8 in) |
| Mounting Pattern | 254 x 114 mm(10 x 4.5 in) |
| Weight kg | 44 kg (97 lbs) |
| Clutch | Manual |
| Certification | CE Certified |
| Layer of Rope/Cable | Line Pull: lbs(kgs) | Rope on drum ft(m) |
|---|---|---|
| 1 | 12000 (5443) | 15.1 (4.6) |
| 2 | 9563 (4338) | 34.1 (10.4) |
| 3 | 7907 (3586) | 57.7 (17.6) |
| 4 | 6755 (3064) | 83.7 (25.5) |
| Line Pulllbs (kgs) | Line Speed 12vft/min (m/min) | Line Speed 24vft/min (m/min) | Amp Draw12v | Amp Draw24v |
|---|---|---|---|---|
| 0 | 29.5 (9.0) | 37.7 (11.5) | 50 | 45 |
| 6000 (2721) | 10.5 (3.2) | 12.1 (3.7) | 240 | 140 |
| 8000 (3629) | 8.2 (2.5) | 9.8 (3.0) | 280 | 180 |
| 10000 (4535) | 5.9 (1.8) | 7.2 (2.2) | 320 | 220 |
| 12000 (5443) | 4.6 (1.4) | 5.2 (1.6) | 380 | 250 |
Old Codes: 120SS12/120SS24
Brand: Warrior Winches
Identifier: 120VS12 120VS24
Brand new packaged items only.
Comes with a full manufacturer warranty (not including consumable products).
