(Item No Longer Available - No Direct Replacement)
Quote Ref: @115082
Product ID: 120VS12
Manufacturer: Warrior Winches
Price: (£395.00 ex VAT) £474.00 (inc VAT)
474.00 2025-06-27Our top performance winches just got better!
Our premium 'Next Generation' Samurai range are even faster, with a lower current draw and now boast a revolutionary external brake, more capable of load holding & lowering, as well as ensuring there's no heat build up in the drum.
Ideal for recovery and 4x4 applications. Outstanding features include high quality series wound double sealed motor with solid brass contacts, heavy duty 4 pin waterproof contactors, double sealed drum on maintenance free bearings and quiet, efficient full steel planetary gearing. Comes with stainless steel roller fairlead and fittings as standard. The 12V version comes complete with heavy duty integrated wireless remote.
Rated Line Pull 12000 lbs (5443 kg)
Motor 12v : 6.7hp / 5.0kw
24v : 8.0hp / 6.0kw
Gearing 253:1
Braking Action External Brake
Drum Size - Dia x L 63 x 223mm
Cable - Dia x L Steel: 10.2mm x 26m
Synth: 11mm x 25m
Dimensions 559 x 160 x 248mm
Mounting Pattern 254 x 114 mm
Weight kg Steel: 44 kg
Synth: 32 kg
Clutch Manual
Certification CE Certified
Layer of Rope/Cable Line Pull: lbs(kgs) Rope on drum ft(m)
1 12000 (5443) 15.1 (4.6)
2 9563 (4338) 34.1 (10.4)
3 7907 (3586) 57.7 (17.6)
4 6755 (3064) 83.7 (25.5)
Line Pull
lbs (kgs) Line Speed 12v
ft/min (m/min) Line Speed 24v
ft/min (m/min) Amp Draw
12v Amp Draw
24v
0 29.5 (9.0) 37.7 (11.5) 50 45
6000 (2721) 10.5 (3.2) 12.1 (3.7) 240 140
8000 (3629) 8.2 (2.5) 9.8 (3.0) 280 180
10000 (4535) 5.9 (1.8) 7.2 (2.2) 320 220
12000 (5443) 4.6 (1.4) 5.2 (1.6) 380 250
Brand: Warrior Winches
Identifier: 120VS12
